- Features
- Utilizing our own wet process, we could offer fine powders with high dispersion,
high packing property and sharp size distribution.
- Applications
(1) Thick film conductive paste (sintering /polymer type)
(2) Electrode material for LTCC / MLCC
(3) Through-hole paste
(4) Conductive adhesive
Copper Powder(Wet process)
- Features
- Utilizing our own designed high-pressure atomized process, we could offer
fine powders . Especially, K series is fine powder with high sphericity
and sharp particle size as compared with conventional items.
- Applications
(1) Thick film conductive paste (sintering /polymer type)
(2) Electrode material for LTCC / MLCC
(3) Through-hole paste
(4) Conductive adhesive
Copper Powder(Atomaization process)
- Features
- We could offer a wide variety of flake/plate shaped powders using our wet
and atomized powders. We could adjust thickness and particle that powders.
- Applications
(1) Thick film conductive paste (sintering /polymer type)
(2) Electrode material for LTCC / MLCC
(3) Through-hole paste
(4) Conductive adhesive
- Features
- Utilizing our own pulverization process, we could offer powders with high
packing property.
- Applications
(1) Through-hole paste
(2) Thick film conductive paste (sintering /polymer type)
(3) Electrode material for LTCC / MLCC
(4) EMI shield
(5) Conductive adhesive
Copper Powder(Electrolytic process)
- Features
- Using advansed technology and accumulated know-how, we developed high performance
Ag coated Cu powders. We could offer powders that meet the required properties
such as dispersity, shape and conductivity.
- Depending on the purpose, particle size, shape, coat ratio can be selected.
In addition, we could also coat other than silver.
Silver coated Copper Powder
- Features
- Utilizing our own wet process, we could offer the powder with high dispersion,
high filling, and sharp size distribution.
- Applications
(1) Thick film conductive paste (sintering /polymer type)
(2) Electrode materials for PV (Photovoltaics)
(3) Electrode materials for Touch panel
(4) Conductive adhesive
- Features
- Fine and uniform thickness with few coarse particles.
We can adjust particle size and thickness as you need.
High conductivity due to flake-to-flake contact.
- Applications
(1) Adhesive material
